Press play or drag the slider bar to show operational fibre optic network in each year from 2009 - 2022.

Liquid Intelligent Technologies

This map shows the reach of Liquid Intelligent Technologies (LIT) regional fibre optic network, which reached 110,000-km during 2023. Liquid's network reached the milestone of 100,000-km in 2021, and 60,000-km five years previously in 2018.

Route Kilometres of LIT's transmission network, Africa 2009 - 2023

Terrestrial Transmission Network

Route Kilometres of terrestrial transmission network, Africa 2013 - 2023

Africa’s total inventory of terrestrial fibre optic transmission networks passed the milestone of 1 million route-kms during 2018. By June 2023 the amount of operational fibre optic network reached 1,279,026-km, compared to 936,102-km in 2018 and 524,847-km in 2013. In the twelve months since June 2022, an additional 94,998-km of fibre optic network has entered service, an average of 260-km of new fibre optic network entering service per day. In addition, there was in June 2023 a further 116,578-km of fibre optic network under construction, 133,830-km planned, and 68,805-km proposed.

Approximately one-fifth of the total fibre inventory in Sub-Saharan Africa is within cities: of the inventory of 1,279,026-km of operational terrestrial fibre in June 2023, at least 294,192-km was metropolitan fibre rings and FTTH/B (fibre-to-the-home/ building) networks. These metro rings distribute bandwidth from fibre optic nodes to districts and suburbs around each city. The FTTH/B networks provide the last mile access, delivering fibre bandwidth right to the door.

Fibre Reach

Fibre Reach, Africa 2013 - 2023. Population within reach of operational fibre optic network (million)

The landing of new submarine cables and expansion of terrestrial transmission networks is bringing additional countries, regions, cities and towns within reach of fibre networks for the first time. In the last year alone, network expansion has brought more than 40 million more people within access to high capacity national and international backbone networks, and in the last ten years more than 338 million.

In June 2023, 60.5% of the population in Sub-Saharan Africa (709 million) was within a 25-km range of an operational fibre optic network node. This compared to 57.1% (669 million) in 2022, 56.7% (647 million) in 2021, 55.9% (620 million) in 2020, 55.2% (584 million) in 2019, 54.2% (556 million) in 2018, 55.2% (522 million) in 2017, 48.1% (469 million) in 2016, 45.8% (436 million) in 2015, 44%, (410 million) in 2014, and 41.8% (371 million) in 2013.

Once the fibre network which is currently under construction enters service, the fibre reach of Sub-Saharan Africa will increase to 62.0% (726 million), and once the network which is planned or proposed enters service it will increase to 66.0% (773 million).

International Internet Bandwidth

International Internet bandwidth (Gbps), Africa 2012 - 2022

Africa’s total inbound international Internet bandwidth reached 36.7 Tbps by December 2022. This compared to 26.4 Tbps in 2021, 21.0 Tbps in 2020, 16.1 Tbps in 2019, and 12.1 Tbps in 2018. This total of 36.7 Tbps in 2022 was split between Sub-Saharan Africa, which increased by 37% to reach 23.8 Tbps, and North Africa which increased by 43% to reach 12.9 Tbps.

Almost two-thirds of all this bandwidth to sub-Saharan Africa is supplied to its three largest markets. South Africa’s inbound international Internet bandwidth was 7.515 Tbps in 2022, Kenya was reported at 4.364 Tbps, and Nigeria had an estimated 2.535 Tbps.

Of the total bandwidth of 23.748 Tbps in Sub-Saharan Africa by December 2022, 21.813 Tbps (91.9%) was supplied directly by submarine cable. This total of 21.813 Tbps was a 253% increase compared to 6.184 Tbps in December 2018.

There is plenty of room for future growth: this figure of 21.813 Tbps is still a fraction of the total design capacity of at least 823.8 Tbps that is potentially now available on the 33 submarine cables serving the region in December 2022. When 2Africa enters service during 2024 (180 Tbps), this will take the total design capacity serving the region to over 1 Pbps.

The completion of new cross-border links, and the expansion of capacity on others, has seen the volume of intra-regional traffic backhauled to submarine cable landing points increase by 35% in the last year to reach 1.914 Tbps in December 2022. This compares to 1.422 Tbps in 2021, 1.112 Tbps in 2020, 713 Gbps in 2019, and 547 Gbps in 2018.
