The Africa Telecom Transmission map is printed on A0-sized (94 cm x 118 cm) canvas, and contains the following features:

  • Exploded view for clearest mapping
  • Main map scale of 1:12,000,000
  • Inset map of Central West Africa scale of 1: 5,000,000
  • Inset map of Eastern and Southern Africa scale of 1: 8,500,000
  • Chart: International Internet Bandwidth (Gbps), Africa 2007 - 2016
  • Chart: Route-kms Terrestrial Transmission Netwok, Africa 2009 - 2017

The map contains the following data for 289 network operators in 55 African countries, and 58 submarine cable systems:

  • Operational fibre optic networks
  • Fibre optic networks under construction
  • Fibre optic networks planned
  • Fibre optic networks proposed
  • Microwave networks operational
  • Microwave networks planned
  • Operational submarine cables
  • Submarine cables under construction
  • Submarine cables planned or proposed
Africa Transmission Map - Hamilton Research

Click here for larger view.

Please feel free to include this map image in your presentations and reports, so long as it is not altered in any way and clearly includes the citation "Source: © Hamilton Research 2017, www.africabandwidthmaps.com".

The 2017 Africa Telecom Transmission Map is sponsored by Liquid Telecom.

Acknowledgements: We would like to thank the dozens of network operators for providing information, and the following organisations for their input and advice into the research and production of this map: Africa Analysis, Balancing Act, CIESIN, ECCAS, ECOWAS, Europa Technologies, Liquid Telecom, WIOCC, and the World Bank.

Countries: Submarine cable systems:
55 African countries:

  • Algeria
  • Angola
  • Benin
  • Botswana
  • Burkina Faso
  • Burundi
  • Cameroon
  • Cape Verde
  • Central African Republic
  • Chad
  • Comoros
  • Congo, Rep
  • Congo, DRC
  • Côte d'Ivoire
  • Djibouti
  • Egypt
  • Equatorial Guinea
  • Eritrea
  • Ethiopia
  • Gabon
  • Gambia
  • Ghana
  • Guinea
  • Guinea Bissau
  • Kenya
  • Lesotho
  • Liberia
  • Libya
  • Madagascar
  • Malawi
  • Mali
  • Mauritania
  • Mauritius
  • Mozambique
  • Namibia
  • Niger
  • Nigeria
  • Reunion
  • Rwanda
  • Sao Tome and Principe
  • Senegal
  • Sierra Leone
  • Somalia
  • South Africa
  • South Sudan
  • Sudan
  • Swaziland
  • Tanzania
  • Togo
  • Tunisia
  • Uganda
  • Zambia
  • Zimbabwe
58 submarine cable systems:

  • AAE-1 (Asia Africa Europe 1)
  • ACE (Africa Coast to Europe)
  • Aden - Djibouti
  • ADONES
  • ALPAL-2
  • Atlantis-2
  • Atlas Offshore
  • Avassa
  • BRICS
  • Cable sous marin l'Afrique Centrale (CSM-AC)
  • Cape Verde Inter-island Submarine Cable
  • CEIBA-1
  • CEIBA-2
  • Djibouti Africa Regional Express (DARE)
  • DIDON
  • EASSy (East African Submarine Cable System)
  • EIG (Europe India Gateway)
  • EUAfrica
  • FALCON
  • FLAG EA (Europe - Asia)
  • FLAG NGN System -2
  • FLY
  • FLY LION 3
  • GBI (Gulf Bridge International)
  • Gombessa
  • GLO-1
  • Hannibal
  • IMEWE (India - Middle East - Western Europe)
  • IOX Cable System
  • Keltra
  • LFON (Libya FIbre Optic Network)
  • Libya - Italy
  • Libya (Tripoli - Benghazi)
  • LION-1 (Lower Indian Ocean Network 1)
  • LION-2 (Lower Indian Ocean Network 2)
  • Liquid Sea
  • LOUKKOS
  • MAIN One
  • METISS (Melting Pot Indianoceanic Submarine System)
  • NCSCS (Nigeria - Cameroon Submarine Cable System)
  • Orval
  • SACS (South Atlantic Cable System)
  • SAIL (South Atlantic Inter Link)
  • SAS-1 (Sudan - Saudi Arabia)
  • SAS-2 (Sudan - Saudi Arabia)
  • SAT-2
  • SAT-3/WASC (West Africa Submarine Cable)
  • SAFE (South Africa - Far East)
  • SEACOM
  • SEAMEWE-3 (South East Asia - Middle East - Western Europe - 3)
  • SEAMEWE-4
  • SEAMEWE-5
  • Silphium
  • SAEx (South Atlantic Express)
  • SEAS (Seychelles East Africa System)
  • TEAMS (The East African Marine System)
  • TE North (Telecom Egypt North)
  • WACS (West Africa Cable System)
